Product Description:
Cost-Effective Metal Die Casting Machine For Budget-Conscious Buyers
Low Pressure Die Casting Machine is a metal die casting machine which can produce high quality metal parts with low pressure and high accuracy.Fully automatic machine with two manipulators mounted on a rotary turning device and one furnace for the cost-effective production of high-quality casting products. It is designed to be an efficient and cost-effective solution for the casting industry. The machine features a powerful force of ejector (up to 1000kg), a voltage of 380V and an air pressure of 0.5-0.6Mpa. Additionally, the gas pressure can reach 0.5bar and the furnace power is 165KW. This Low Pressure Die Casting Machine is ideal for producing complex metal parts with precision and accuracy. It is also suitable for high volume production, with its robust construction and fast cycle times. With its superior performance and reliable operation, this machine is a great choice for casting applications.
Features:
- Product Name: Low Pressure Die Casting Machine
- Cooling System Water Temperature: 20±2℃
- Equipment Size:L*W*H: 7000*6000*4200mm
- Hydraulic Motor Power: 12KW
- Hydraulic Rated Pressure: 8Mpa
- Total Power: 180KW
- Metal Dia Casting Machine
- Low Pressure Die Casting Machine
Technical Parameters:
| Parameters |
Value |
| Metal Dia Casting Machine |
Low Pressure Die Casting Process |
| Total Power |
180KW |
| Total Weight |
20T |
| Max. Force of Ejector |
1000kg |
| Hydraulic Fluid Temperature |
≤55℃ |
| Cooling System Water Temperature |
25-30℃ |
| Gas Flow |
0.225m³/h |
| Compressed Air Pressure |
0.5-0.6Mpa |
| Gas Pressure |
0.5bar |
| Cooling System Flow |
≥300L/Min ≤600L/Min |
| Furnace Power |
165KW |
Applications:
The DZ RD-5040-S Low Pressure Die Casting Machine is a revolutionary process and technology for casting metal parts with superior precision. It is designed to meet the highest standards in terms of safety and reliability and is certified with a CE ISO certification. With a total power of 180KW and a furnace power of 165KW, it provides a melting rate of up to 680KG/H and operates on a voltage of 380V. This Low Pressure Casting Machine also features a compressed air pressure of 0.5 - 0.6Mpa, creating an ideal environment for the low pressure die casting process.
The Low Pressure Die Casting Machine is an excellent choice for industrial applications that demand accuracy, consistency, and precision. Its powerful motor and robust design can handle a variety of tasks, from casting intricate components to manufacturing large parts. It is suitable for a wide range of industries, including automotive, aerospace, medical, and electronics. The machine is also highly reliable and durable, making it an ideal solution for any kind of long-term production.
The DZ RD-5040-S Low Pressure Die Casting Machine is a reliable and efficient machine for casting parts with superior precision. It is a perfect choice for industrial applications that require accuracy, consistency, and precision. With its robust design and powerful motor, it is suitable for a wide range of industries and can handle a variety of tasks, from casting intricate components to manufacturing large parts. It is also highly reliable and durable, making it an ideal solution for any kind of long-term production.
Support and Services:
We provide technical support and service for Low Pressure Die Casting Machine. Our technical support team are available to provide troubleshooting and advice, as well as maintenance and repair services.
Our experienced engineers can advise on the best set up for your machine and will guide you through the installation process. We also provide regular maintenance and repair services to keep your machine running smoothly.
We also offer training courses to help you get the most out of your Low Pressure Die Casting Machine. Our team of experts can provide advice, guidance and support to ensure your machine is working optimally.
We are committed to providing the highest level of customer service and technical support. If you have any questions or need help with your Low Pressure Die Casting Machine, please do not hesitate to contact us.
Packing and Shipping:
The Low Pressure Die Casting Machine will be packaged securely in a wooden crate. It is then strapped to a pallet and shrink wrapped for added protection during shipping. The Low Pressure Die Casting Machine will be shipped via a reliable freight company.
