CNC System Automatic Grinding Machine / Robot Grinding Polishing Machine For Faucet
Main Features
1). Robot body: fully-automatic control, repeatable edition, able to complete all kinds of polishing in three-dimensional space, and brands are optional.
2). Abrasive band grinding machine: equipped with multiple usable grinding contact wheels. When grinding, the robot can control rotating speed and automatically adjust tension of abrasive band, and automatically choose currently available contact wheel.( Users can decide quantity of abrasive band grinding machine, according to their own needs.)
3). Two-station automatic feeding table: double-station elements arrangement, alternate operation, the two stations can set same or different products at the same time, the robot can recognize different programs and operate accordingly.
4). Positioner: adopt pneumatic drive, posses functions of air pressure, cable rotation, and also the pioneering displacement detection, which can avoid the positioner from working when the placement is incorrect. Or the machine or PU wheel might get damaged.
5). Whole machine control system: automatic linear speed compensation, abrasive band rectification, grinding pressure compensation, remote fault diagnosis and repair.
| TECHNICAL PARAMETERS |
| To fulfill the different product weight and sizere quirement,different requirements for belt sander of customers,we have 4 models for customer options. |
| | 20GA Specifications | 20GBSpecifications | 35GSpecifications | 50GSpecifications |
| Robot Cell | FUNAC | FUNAC | FUNAC | FUNAC |
| Robot Model | 20iA/20 | 20iA/20 | 20iA/35 | 20iA/50 |
| Rated Voltage | 380V | 380V | 380V | 380V |
| Machine Power | 7.6KW | 10.5KW | 11KW | 16KW |
| Sand Belt Machine Quantity | 1 | 2 | 2 | 2 |
| Sand Belt Quantity | 4 | 4 | 4 | 4 |
| Sand Belt Dimensions | 3000mm×4 | 3000mm×4 | 4000mm×4 | 4000mm×4 |
| Feed Table | 1 | 1 | 1 | 1 |
