CNC Control Robotic Buffing Machine / Polishing / Finishing Machine For Brass Casted Faucets

Brand Name : DZ

Model Number : NC-62

Certification : CE ISO

Place of Origin : China

MOQ : 1

Payment Terms : L/C, T/T, Western Union

Supply Ability : 30sets /per day

Delivery Time : 30days

Packaging Details : wood

Weight : 6000KG

Voltage : 380V/50Hz

Condition : 100%New

After-sales service provided : Engineers available to service machinery overseas,Video technical support,Online support,Field maintenance and repair service,Field installation

Application : Buffing ,Polishing

Control system : PLC

Warranty : 1 Year

Name : Fully automatic polishing machine

Function : polishing granite

Usage : Metal Stainless Steel Tank grinding and buffing machine

Contact Now

Deburring, Polishing, Brightening For Brass Casted Faucets, Zamak,Zamak Faucets, Shower Heads And Any Sanitary

I.TECHNICAL PARAMETERS

No	Items	Specifications
1	Dimensions (LWH)	300031002900mm
2	Machine Power	17KW
3	Rated Voltage	380V
4	Max. Diameter of polishing wheel	600mm
5	Min. Diameter of polishing wheel	400mm
6	X-Axis travel (mm)	1100
7	Y-Axis travel (mm)	900
8	Z-Axis travel (mm)	700
9	U-Axis travel (mm)	±60°
10	V-Axis travel (mm)	±360°
11	W-Axis travel (mm)	±360°
12	Max.speed X axis	20m/min
13	Max.speed Y axis	20m/min
14	Max.speed Z axis	20m/min
15	Max.speed U axis	30°/sec.
16	Max.speed V axis	30°/sec.
17	Max.speed W axis	30°/sec.

II.FEATURES

Sypical products to process: Brass casted faucets, zamak
levers,zamak faucets, shower heads and any sanitary ware
Rotary transfer with CNC control system
Multi-purpose Machine: Deburring, Polishing, Brightening Satin
Easy and intuitive teach-in programming system
Pressure control: disc wear control with automatic
compensation
High productivity: 4 simultaneous part processing
High adaptability: Multiple geometries processin
Ultra flexible: multi part flow. Up to 4 simultaneous parts processing
Model change in seconds
Quick change of consumables and grippers
Low operating cost: energy efficient, minimized consumption of discs and compound
